153L to 120B Series HX4T (3500 RPM) Comparisons

Back to Aurora Replacements

Click and drag your mouse on the curve. Lines are automatically drawn as either horizontal or vertical. To clear the canvas, click the "Clear Lines" button below the curve.

Zoom

Clear Lines

Notes: Do not exceed 1150 TDH with 1.0 S.G. fluids.
Consult factory for operation below 29 GPM.
*Consider 250 Series inducer if pumping at low NPSH. Add 1 horsepower for 250 Series models.
**Horsepower data is valid for 1.0 specific gravity fluids only. Data provided is based of performance testing with water.
